Skill: Siev

US Patent No. 7,905,753

Coupler connector

A coupler connector and cross talk reducing network for coupling a first cable and a second cable in electrically conducting relation to each other, the first cable and the second cable respectively terminated by a first modular plug and a second modular plug each comprising respectively a first plurality of contact terminals and a second plurality of contact terminals.
US7905753B2 – Coupler connector – Google Patents

US Patent No. 7,883,376

Connector with insulation piercing contact for terminating pairs of bonded conductors

There is disclosed a connector and method for terminating a cable comprised twisted pairs of conductors. In one aspect of the invention the connector comprises a wire lead guide for arranging the twisted pairs of conductors and a plurality of piercing contacts which interconnect with respective ones of the twisted pairs of conductors when the wire guide is secured to the module. In a further aspect of the invention the wire lead guide ensures that the spacing between the conductors of a particular twisted pair is maintained, thereby improving the performance of the subsequent assembly.

US Patent No. 7,837,513

Telecommunications connector

A contact element and mechanism for use in a connector, the connector comprising a socket adapted for receiving a cable plug comprising a terminal contact. The contact element and mechanism comprise a flexible dielectric substrate and a first conductive strip on a first surface of the substrate. When the plug is inserted into the socket, the terminal contact comes into contact with the conductive strip.
There is also provided a compensating connector for interconnection with a cable plug, the plug comprising a plurality of terminal contacts. The connector comprises a socket adapted for receiving the plug, a plurality of contact elements disposed in the socket, each of the contact elements comprising a conductive strip, and a compensation network comprised of a plurality of compensating elements. Each of the compensating elements is located adjacent to one of the contact elements. When the plug is inserted into the socket, each of the terminal contacts comes into contact with a predetermined one of the conductive strips.

US Patent No. 7,670,193

Connector with insulation piercing contact and conductor guiding passageway

There is disclosed a connector and method for terminating a cable comprised twisted pairs of conductors. In one aspect of the invention the connector comprises a wire lead guide for arranging the twisted pairs of conductors and a plurality of piercing contacts which interconnect with respective ones of the twisted pairs of conductors when the wire guide is secured to the module. In a further aspect of the invention the wire lead guide ensures that the spacing between the conductors of a particular twisted pair is maintained, thereby improving the performance of the subsequent assembly.

US Patent No. 7,568,938

Balanced interconnector

There is disclosed a balanced interconnector comprising first and second like connecting elements, each of the connecting elements comprising an elongate centre section and a pair of parallel IDCs opening in substantially opposite directions, the IDCs attached substantially at right angles to and at opposite ends of the elongate centre sections, each of the connecting elements lying in different parallel plains. The first and second connecting elements are arranged such that the elongate centre sections are opposite one another and the IDCs of the first connecting element are not opposite the IDCs of the second connecting element. In a particular embodiment the connecting elements of adjacent pairs of connecting elements are at right angles.

US Patent No. 7,614,901

Balanced interconnector

There is disclosed a balanced interconnector comprising first and second like connecting elements, each of the connecting elements comprising an elongate center section and a pair of parallel IDCs opening in substantially opposite directions, the IDCs attached substantially at right angles to and at opposite ends of the elongate center sections, each of the connecting elements lying in different parallel plains. The first and second connecting elements are arranged such that the elongate center sections are opposite one another and the IDCs of the first connecting element are not opposite the IDCs of the second connecting element. In a particular embodiment the connecting elements of adjacent pairs of connecting elements are at right angles. The positioning and geometry of the connecting elements.

US Patent No. 7,422,467

Balanced interconnector

There is disclosed a balanced interconnector comprising first and second like connecting elements, each of the connecting elements comprising an elongate center section and a pair of parallel IDCs opening in substantially opposite directions, the IDCs attached substantially at right angles to and at opposite ends of the elongate center sections, each of the connecting elements lying in different parallel plains. The first and second connecting elements are arranged such that the elongate center sections are opposite one another and the IDCs of the first connecting element are not opposite the IDCs of the second connecting element. In a particular embodiment the connecting elements of adjacent pairs of connecting elements are at right angles. The positioning and geometry of the connecting elements.

US Patent No. 11,258,204

Compensating connector system

A connector and assembly of a cabling category and comprising two mating zones connected by an intermediate zone. Each of the zones is manufactured such that Near End Cross Talk (NEXT) resulting from transmission of the high frequency signal across each zone is below a specified amount chosen such that NEXT introduced by a high frequency signal transmission between via all the zones is below a level as specified for the cabling category.

US Patent No. 10,897,101

Coupler connector and cable terminator with side contacts

An assembly comprising a cable terminator comprising a wire guide, a cube shaped securing cap comprising an open end for installation over the wire guide, and pairs of piercing contacts for piercing respective conductors of the cable. When assembled, an outer end of each of the piercing contacts is exposed on an outer surface of a respective securing cap sidewall. The assembly also comprises a coupler connector comprising one of a modular (for example RJ-45 compatible) socket or a modular (for example RJ-45 compatible) plug, a rearward surface comprising a cable terminator receiving socket, wherein pairs of contacts are exposed along at least one side wall of the socket, and further wherein each of a plurality of the tines in the modular socket or the terminal contacts of the plug is interconnected with a respective one of the contacts.

US Patent No. 10,476,197

Coupler connector and cable terminator with side contacts

An assembly comprising a cable terminator comprising a wire guide, a cube shaped securing cap comprising an open end for installation over the wire guide, and pairs of piercing contacts for piercing respective conductors of the cable. When assembled, an outer end of each of the piercing contacts is exposed on an outer surface of a respective securing cap sidewall. The assembly also comprises a coupler connector comprising one of a modular (for example RJ-45 compatible) socket or a modular (for example RJ-45 compatible) plug, a rearward surface comprising a cable terminator receiving socket, wherein pairs of contacts are exposed along at least one side wall of the socket, and further wherein each of a plurality of the tines in the modular socket or the terminal contacts of the plug is interconnected with a respective one of the contacts.
